Wi-Fi 6 (802.11ax) : The IEEE 802.11ax emerging standard, also known as High-Efficiency Wireless (HEW) or Wi-Fi 6, builds on 802.11ac. It delivers a better experience in typical environments with more predictable performance for advanced applications such as 4K or 8K video, high-density, high-definition collaboration apps, all-wireless offices, and IoT. Wi-Fi 6 is designed to use both the 2.4-GHz and 5-GHz bands, unlike the 802.11ac standard.
Interfaces: 1x Gigabit Ethernet (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
Maximum clients: Maximum number of associated wireless clients: 200 per Wi-Fi radio, for a total of 400 clients per access point, or 1000 in a system.
Maximum number of associated Cisco Business mesh extenders: 25 per Access Point, up to 8 hops
Authentication and security:
Wi-Fi Protected Access - with WPA2 or WPA3, including WPA2-Entperprise authentication
● 802.1X, RADIUS Authentication, Authorization, and Accounting (AAA)
● Segmentation via VLANs (up to 16)
● 802.11r and 802.11i
802.11ax : 2x2 downlink MU-MIMO with two spatial streams, PHY data rates up to 1.488 Gbps (80 MHz with 5 GHz and 20 MHz with 2.4 GHz)
802.11ac : 2x2 single-user/multi-user MIMO with two spatial streams, up to 867 Mbps in 5GHz
System : 1 GB DRAM, 512MB flash and 1GHz quad core processor
