HSGQ / OLT

HSGQ-G08R

HSGQ 8*Port Pon GPON OLT Integrated Ftth Access

Key Features
  • 4 × GPON Ports — Supports up to 512 ONUs with 1:128 split ratio
  • Gigabit Uplinks — 4 × 1G SFP + 4 × Gigabit Combo ports for strong backbone
  • Layer 2+ Management — VLAN, QoS, IPv6, SNMP, CLI & TR069 support
  • Compact 1U Design — Low power consumption with optional redundant power
Brand HSGQ
Category OLT
Model HSGQ-G08R
Availability In Stock
General
Device Type 4-Port GPON OLT (Pizza-Box)
Form Factor 1U Rackmount
Physical
Dimensions 442 × 227 × 43.6 mm
Weight ≈ 3.7 kg
PON Features
PON Type GPON (ITU-T G.984)
GPON Port 4 × GPON SFP (Class C+/C++)
EPON Port N/A
XPON Support GPON
Split Ratio 1:128 per PON port
Max ONU Support Up to 512 ONUs (128 per PON port)
Interface
Uplink Port 4 × 1G SFP + 4 × Gigabit Combo (RJ45/SFP)
SFP Port 4 × 1G SFP
Combo Port Yes (4 Combo Ports)
Console Port Yes (RJ45)
Management Port Yes
Performance
Switching Capacity High (Non-blocking)
Forwarding Rate Wire-speed
Features
VLAN Yes (802.1Q, QinQ, Port-based)
QoS Yes (Advanced QoS)
IPv6 Support Yes
Layer Support Layer 2+
TR069 Support Yes
Management
Web Management Yes
CLI Yes (CLI, SNMP, Telnet, SSH)
SNMP Yes (CLI, SNMP, Telnet, SSH)
Power
Power Supply AC 100–240V
Power Consumption ≤ 40W
Redundant Power Support Optional
Environment
Operating Temperature 0°C ~ 45°C
Humidity 10% ~ 90% (non-condensing)
Others
Package Content 1 × SOL1004-1G-DP OLT, Rackmount Kit, Power Cord, Console Cable, User Manual
Warranty & Support
Warranty 1 Year Official Warranty
