HSGQ-Z110 Single Port XPON High-Speed Gigabit ONU

Key Features
  • Single Gigabit Ethernet port designed for connecting external WiFi router
  • Dual-mode XPON (GPON/EPON) with automatic detection
  • Ultra-compact size with very low power consumption
  • Supports TR-069 remote management and IPTV services
Brand HSGQ
Category ONU
Model HSGQ-Z110
Availability In Stock
General
ONU Type Single Port XPON ONU
Color White
Network
XPON Support Yes (Dual Mode)
GPON Standard ITU-T G.984
EPON Standard IEEE 802.3ah
WAN Type XPON
Wireless
WiFi Standard N/A
WiFi Frequency N/A
WiFi Speed N/A
Antenna Quantity N/A
Antenna Gain N/A
Interface
LAN Port 1 Port
LAN Port Speed 10/100/1000 Mbps
PON Port 1x SC/APC
RJ11 Port N/A
CATV Port N/A
Features
VoIP Support No
IPTV Support Yes
IPv6 Support Yes
TR069 Support Yes
Mesh Support No
Optical
Optical Connector SC/APC
Optical Wavelength Tx 1310nm, Rx 1490nm
Receiving Sensitivity -28 ~ -8 dBm
Power
Power Supply DC 9V / 0.6A
Power Consumption ≤ 6W
Physical
Dimensions 120 × 80 × 28 mm (Approx.)
Weight ≈ 150g
Hardware
Chipset High Performance XPON SoC
LED indicator PWR, PON, LOS, LAN
Flash Memory 128MB
Button Reset Button
Warranty & Support
Warranty 1 Year Official Warranty
