MR-US10K

Marsriva MR-US10K On-Line UPS

Key Features
  • True Online Double Conversion with 0ms Transfer Time & Pure Sine Wave
  • 10KVA/10KW Output (PF 1.0) + High Efficiency up to 95.5%
  • Long Run External Battery Support (192V DC) for extended backup
  • LCD Display, RS232/USB/EPO, Intelligent Charging, Wide Input Range & 1 Year Warranty
Brand Marsriva
Category UPS
Model MR-US10K
Availability In Stock
General
UPS Type Online UPS (True Double Conversion, High Frequency, DSP Controlled)
Color Black
Power
Capacity 10KVA
Rated Power 10KW (Power Factor 1.0)
Input Voltage 208/220/230/240 VAC (Single Phase)
Output Voltage 208/220/230/240 VAC (±1%)
Output Frequency 50/60Hz ±0.1% (Battery Mode)
Waveform Type Pure Sine Wave
Transfer Time 0 ms (to Battery), 4 ms (to Bypass)
Efficiency Up to 95.5% (AC Mode)
Battery
Battery Type Sealed Lead-Acid, Maintenance-Free (External – Long Run Model)
Battery Capacity External Battery Bank (configurable)
Battery Quantity External (Typically 192V DC system)
Backup Time Long Run (Depends on external battery bank — minutes to hours)
Battery Voltage 192V DC
Interface
AC Output Port Terminal Block (L+N+PE)
DC Output Port None
USB Port Yes (USB + RS232, EPO, Smart Card Slot)
PoE Output No
Connector Type Terminal Block Input/Output
LED Indicator Yes (Multifunction LCD Display)
Power Button Yes
Protection
Overload Protection Yes (with timed levels)
Short Circuit Protection Yes
Overcharge Protection Yes
Surge Protection Yes
Overheat Protection Yes
Features
Auto Restart Yes (Auto restart when AC recovers)
Cold Start Yes
AVR Support Not required (True Online Double Conversion)
Silent Mode Low noise operation (<50dB)
Smart Charging Yes (Intelligent 3-stage charging, adjustable)
Physical
Dimensions 438 × 88 × 385 mm (or 460 × 190 × 615 mm in some tower variants)
Weight Approx. 7–20 kg (Net, without external batteries)
Material Metal Housing
Warranty & Support
Warranty 1 Year Official Warranty
