EW2110-3000C

Must / UPS

EW2110-3000C

Must EW2110-3000C 3000VA/1800W Line Interactive UPS (LCD Version)

Key Features
  • 3000VA / 1800W capacity with LCD display (C series)
  • 4 × 12V/9Ah batteries (48V system) & 4–6 hours recharge
  • AVR, Cold Start, Auto Restart, CPU control & Generator compatible
  • Fast 2–6 ms transfer time + full protections (Overload, Short Circuit, Low Voltage)
Brand Must
Category UPS
Model EW2110-3000C
Availability In Stock
General
UPS Type Smart Line Interactive UPS (with AVR)
Color Black
Power
Capacity 3000VA
Rated Power 1800W
Input Voltage 220/230/240 VAC (or 110/120V variant)
Output Voltage 220/230/240 VAC
Output Frequency 50Hz / 60Hz ±0.5 Hz (Auto sensing)
Waveform Type PWM / Simulated Sine Wave (Battery Mode)
Transfer Time Typical 2–6 ms, Maximum 10 ms
Efficiency High efficiency with AVR
Battery
Battery Type Sealed Lead-Acid, Maintenance-Free
Battery Capacity 12V / 9Ah × 4 pcs
Battery Quantity 4
Backup Time Depends on load (typically several minutes at full load, longer at lower loads)
Battery Voltage 48V DC (4 × 12V)
Interface
AC Output Port Multiple Universal Sockets
DC Output Port None
USB Port Optional (RJ45/11 & USB management)
PoE Output No
Connector Type AC Input + AC Outputs
LED Indicator Yes (LCD Display)
Power Button Yes
Protection
Overload Protection Yes
Short Circuit Protection Yes
Overcharge Protection Yes
Surge Protection Yes
Overheat Protection Yes
Features
Auto Restart Yes (Auto restarts when AC recovers)
Cold Start Yes
AVR Support Yes (Automatic Voltage Regulation)
Silent Mode Yes (Silence setup available)
Smart Charging Yes (Automatic / Offline charging)
Physical
Dimensions 412 × 145 × 210 mm (W × H × D)
Weight Approx. 20 kg (Net)
Material Plastic Case
Warranty & Support
Warranty 1 Year Official Warranty
