General
| Device Type |
100GBASE-SR4 QSFP28 Optical Transceiver |
| Form Factor |
QSFP28 |
Optical
| SFP Type |
100GBASE-SR4 |
| Connector Type |
MPO-12 (12-Fiber Multi-mode) |
| Optical Wavelength |
850 nm (VCSEL) |
| Transmission Distance |
70m on OM3 / 100m on OM4 / OM5 MMF |
| Fiber Type |
Multi-Mode Fiber (MMF) |
| TX Power |
-8.4 ~ +2.4 dBm |
| RX Sensitivity |
≤ -10.3 dBm |
Performance
| Data Rate |
103.125 Gbps (4 × 25.78125 Gbps) |
| Operating Mode |
Multi-Mode Parallel Optics (4 lanes) |
Compatibility
| Compatible Devices |
Cisco, Huawei, Arista, Juniper, Dell, Mellanox, FS, and most QSFP28 compatible switches/routers |
Physical
| Dimensions |
72.0 × 18.35 × 8.5 mm |
| Weight |
≈ 30 g |
Environment
| Operating Temperature |
0°C ~ 70°C |
Others
| Package Content |
1 × Solitine 100G SR4 QSFP28 Module, 1 × Dust Cap |
Warranty & Support
| Warranty |
1 Year Official Warranty |
Solitine 100G SR4 QSFP28 850nm MPO Module (100m)
The Solitine 100G SR4 QSFP28 is a high-speed multi-mode transceiver designed for short-range 100G Ethernet connections. It uses 850nm wavelength and MPO-12 connector, delivering 100Gbps aggregate bandwidth up to 100 meters over OM4/OM5 multi-mode fiber. Ideal for data center interconnects and high-density 100G networking.
100G Short-Range Performance
Supports 4 parallel 25G lanes with 850nm VCSEL technology. Provides up to 70m on OM3 and 100m on OM4/OM5 multi-mode fiber with low latency and high reliability.
MPO-12 Connector & DDM Support
Standard MPO-12 multi-mode connector with Digital Diagnostic Monitoring (DDM) for real-time performance monitoring. Hot-pluggable QSFP28 form factor for easy deployment.
Data Center Optimized
Widely used in high-density data centers, server-to-switch, and switch-to-switch links requiring cost-effective high-bandwidth connectivity.
The Solitine 100G SR4 QSFP28 is a reliable and cost-effective solution for short-range 100G networking.
