TEG2226F

Tenda / Managed switch

TEG2226F

Tenda TEG2226F 24-Port Gigabit Cloud Managed Ethernet Switch with 2 SFP

Key Features
  • 24×Gigabit RJ45 ports + 2×Gigabit SFP uplinks
  • 52 Gbps switching capacity with cloud management
  • Loop detection and unauthorized DHCP alerting
  • Fanless design with rackmount support
Brand Tenda
Category Managed switch
Model TEG2226F
Availability In Stock
General
Switch Type Cloud Managed Gigabit Switch
Layer L2
Form Factor 1U Rackmount / Desktop
Ports
Total Ports 26
RJ45 Ports 24
Gigabit Ports 24 × 10/100/1000 Mbps
SFP Ports 2 × 1000 Mbps SFP
Uplink Ports 2 × Gigabit SFP
Console Port No
PoE
PoE Support No
PoE Standard N/A
PoE Ports 0
PoE Budget N/A
Max Power per Port N/A
Performance
Switching Capacity 52 Gbps
Forwarding Rate 38.69 Mpps
MAC Address Table 8K
Jumbo Frame Supported
Features
VLAN Yes (QVLAN)
QoS Yes
Link Aggregation Yes
IGMP Snooping Yes
Port Isolation Yes
Port Mirroring Yes
Storm Control Yes
Security
Port Security Yes
ACL Yes
802.1X No
Loop Protection Yes (Loop Detection)
Management
Web UI Yes
Cloud Management Yes (Tenda CloudFi)
SNMP No
CLI Limited
Plug & Play Partial (Cloud)
Power
Power Supply AC 100-240V, 50/60Hz
Power Consumption <15W
Lightning Protection 6kV
Physical
Dimensions 440 × 240 × 44 mm
Weight ≈ 3.0 kg
Mounting Rackmount / Desktop
Fan Fanless
Environment
Operating Temperature 0°C to +40°C
Humidity 10% ~ 90% (non-condensing)
Standards
IEEE Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
Warranty & Support
Warranty 1 Year Official Warranty
