HSGQ-842

HSGQ PoE XPON ONU

Key Features
  • Industrial-grade 4GE PoE XPON ONU with metal casing for harsh environments
  • 4x Gigabit LAN ports with PoE output (Total up to 60W)
  • Dual-mode XPON (GPON/EPON) with wide temperature range (-40°C to 75°C)
  • Ideal for IP camera, WiFi AP, and industrial FTTH/FTTB deployments
Brand HSGQ
Category ONU
Model HSGQ-842
Availability In Stock
General
ONU Type Industrial PoE XPON ONU
Color Metal Gray / Black
Network
XPON Support Yes (Dual Mode)
GPON Standard ITU-T G.984
EPON Standard IEEE 802.3ah
WAN Type XPON
Wireless
WiFi Standard N/A
WiFi Frequency N/A
WiFi Speed N/A
Antenna Quantity N/A
Antenna Gain N/A
Interface
LAN Port 4 Ports
LAN Port Speed 4x 10/100/1000 Mbps (PoE Supported)
PON Port 1x SC/APC
RJ11 Port N/A
CATV Port N/A
Features
VoIP Support No
IPTV Support Yes
IPv6 Support Yes
TR069 Support Yes
Mesh Support No
Optical
Optical Connector SC/APC
Optical Wavelength Tx 1310nm, Rx 1490nm
Receiving Sensitivity -28 ~ -8 dBm
Power
Power Supply AC 100~240V (Built-in) / PoE Input Option
Power Consumption ≤ 6W (Device) / PoE Output up to 60W Total
Physical
Dimensions 200mm (L) * 135mm (W) * 40mm (H)
Weight ≈ 450g (Metal Housing)
Hardware
Chipset High Performance Industrial XPON SoC
LED indicator PWR, PON, LOS, LAN1-4, PoE
Flash Memory 128MB+
Button Reset Button
Warranty & Support
Warranty 1 Year Official Warranty
